Lanco Type PVC Pipe Thread Cutting Machine Manufacturer

Lanco Type PVC Pipe Threading Machines by Industrial Machinery Corporation
PRICE & QUOTATION
Starting From US$ 4,000
Choose options
Set quantity
Request quotation

Select the required model and specifications to request your quotation.

Review Lanco Type PVC Pipe Thread Cutting Machine for your component and the required production operation.

Define the component to be produced

This equipment is selected to cut external PVC pipe threads using a compatible Lanco type die head and threading chasers. A manufacturing enquiry needs the actual finished-part drawing and the condition of the starting material. List PVC pipe dimensions, wall section, thread form, pitch and required cut length. Where several components are planned, separate their quantities and dimensions so that a model suitable for one item is not assumed to cover the entire range.

Match the process and tooling

Ask IMC to review die-head interface, chaser suitability, pipe holding and end access for the component schedule. Clarify which tools are included for the first job and which are needed for a changeover. Compare a die-head PVC threader with a lathe-type setup by the actual internal or external operation required. Preparation, material handling and any subsequent operation should appear in the production plan alongside this process.

Establish acceptance before ordering

A representative component should be checked for thread profile, fitting engagement and pipe-wall condition. State the drawing requirements and how the result will be assessed. Use the published specifications to shortlist the model, then send the material and batch information with your chosen quotation options. Agree the supplied tooling, power requirements and support scope in the written offer.

Information to send with your enquiry

  • PVC pipe dimensions
  • Wall section
  • Thread form
  • Pitch and required cut length

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Tags

Lathe Type PVC Pipe Threading Machine, Lanco Type PVC Pipe Threading Machines, Industrial machinery Manufacturer in India, automatic pipe threading machine, electric pipe threading machine price in india
CONFIGURE YOUR MACHINE

Available options

Select the required options and add this machine to your quotation.

Available Options


Your selected configuration is stored in the existing Quote List flow for review before enquiry.

Product Videos

View full playlist on YouTube
TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

Industrial Machinery Corporation was formed in the year 2001 with the motive of designing and exporting industrial machines to all the users who have been in need of these machines for their business purposes. Since then only, we are striving and endeavoring hard to sustain the position that has been awarded by the market and i.e. of the most formidable, talented, and promising manufacturers of industrial machines. Over all these years of being in business, we have concentrated totally on maintaining the quality of our wide chain of machines. One such machine that is made using the latest technology and techniques is the PVC pipe threading machine. In our PVC pipe threading machine, the expertise and craftsmanship that we have permeated is clearly visible and this is the reason why our PVC pipe threading machine has been able to pass all the stern tests and parameters set by the world of industrial machine manufacturers. Our PVC pipe threading machine has been liked and admired by all in every respect be it design, performance, compatibility, efficiency, reliability, dependability, competency, and cost factors. Upon every order, we take full note of customization requirements made by the clients and we make sure that all the customization features are exactly given in the PVC pipe threading machine. This is the reason why no pipe threading machine of any brand has ever been able to surpass the sales record of a PVC Pipe Threading Machine made at an industrial machinery corporation. ?

Generally a PVC pipe threading machine is used in factories and tool rooms to cut fine threads on PVC pipes using the chasing method. In the chasing method, there are least chances of cutting-related flaws as in this method, the PVC pipe threading machine makes the PVC pipe stay unmoved in one place and allows the die head to rotate around the pipe to create accurately cut threads. PVC pipe threading machine uses HSS Tangential chasers are there is a wide variety of threads that this machine can cut but it depends on the type of chaser being installed at that point in time.

Listed below are the names of threads, our PVC pipe threading machine made at Ludhiana based unit can cut:
• BSP
• MATRIX
• BSPT
• NPT
• UNF
• UNC
• BSW
• Acme Threads

Apart from this, while we are in the process of manufacturing our PVC pipe threading machine, we make sure that we are using the latest machinery, most updated technology and techniques, and the most advanced robotic system to make sure that the machine we are about to create comes out to be the most updated version of a PVC pipe threading machine. We make sure that the raw material that is used is of the best quality and for this purpose, our quality supervision team keeps a strict eye on every piece of raw material supplied to be sure that only the best of raw material is used to make this PVC Pipe Threading Machine. For all these ten years, we have used all the business rules and ethics, the latest technology, skills, expertise, and a robotic system to make sure that each and every client buying our machine gets immensely satisfied by each and every machine that we supply to them.

Here are the names of various parts of the PVC pipe threading machine that we make at our manufacturing unit based in Ludhiana:

• Base
• Head Stock
• Saddle • Pillar Or Bed Type Clamping Vice
•Die Head


PVC Pipe Threading Machine Specifications:


Model

3/8" to  2"

(10MM to 50MM)


 1/2" to 2.1/2"

(12MM to 65MM)

1" to 4"

(25MM to 100MM)

2.½ to 6"

(65MM to 150MM)

4" to 8"

(100MM to 200MM)

8" to 10"

(200MM to 250MM)

Saddle Movement10" - 12"16"10“ - 12"8"8"8"
Spindle Speed Range127-18060-90-12040-75-11525-5025-5010-20-30
Number of Spindle Speed233223
Threading Capacity3/8" to 2"1/2" to 3"1" to 4"2.1/2" to 6"4" to 8"8" to 10"
Production per Hour100-12070-9035-4020-2515-2015-20
H.P. Required3 H.P.7.5 H.P.12.5 H.P. 96015 H.P. 96020 H.P. 96030 H.P. 960
Lead ScrewProvidedProvidedProvidedProvidedProvidedProvided
Weight (KG) Approx.55099016001900

2500


5000


Frequently Asked Questions About Lanco Type PVC Pipe Threading Machines

Review PVC joint specification and tooling compatibility against the finished-component drawing before comparing models. No. Confirm the tool profile and suitability for the actual plastic pipe application before using or ordering the chasers.

Include PVC joint specification and tooling compatibility, your material specification and required output. Describe how the workpiece arrives at this operation and where it goes next, so tooling, handling and any accessories can be discussed as part of the proposed setup.

Use the options listed on this product page and add the required quantity to your Quote List. In the final enquiry, identify PVC joint specification and tooling compatibility, destination and electrical supply. Any tooling, installation or spare-part requirement should be stated explicitly for inclusion in the offer.

RELATED PRODUCTS

PVC Pipe Threading Machine
