Pipe Chamfering & Deburring Machine Manufacturer

Pipe End Facing Machine by Industrial Machinery Corporation

Pipe End Facing Machine by Industrial Machinery Corporation thumbnail

Review Pipe Chamfering & Deburring Machine for your component and the required production operation.

Define the component to be produced

This equipment is selected to prepare pipe ends through the specified facing, chamfering or deburring operation. A manufacturing enquiry needs the actual finished-part drawing and the condition of the starting material. List pipe material, diameter, wall thickness and the finished end-profile drawing. Where several components are planned, separate their quantities and dimensions so that a model suitable for one item is not assumed to cover the entire range.

Match the process and tooling

Ask IMC to review cutters, pipe holding, end location and access to the surfaces being prepared for the component schedule. Clarify which tools are included for the first job and which are needed for a changeover. Show the required end profile clearly; facing, chamfering and deburring are related but distinct operations. Preparation, material handling and any subsequent operation should appear in the production plan alongside this process.

Establish acceptance before ordering

A representative component should be checked for face geometry, chamfer dimensions where required and removal of unwanted burrs. State the drawing requirements and how the result will be assessed. Use the published specifications to shortlist the model, then send the material and batch information with your chosen quotation options. Agree the supplied tooling, power requirements and support scope in the written offer.

Information to send with your enquiry

Pipe material
Diameter
Wall thickness and the finished end-profile drawing

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Available options

Select the required options and add this machine to your quotation.

Available Options

Maximum Length Required

Min And Max Diameter of the Job

Expected Price

Purchase

Your selected configuration is stored in the existing Quote List flow for review before enquiry.

VIDEO REFERENCE

Machine Videos Gallery

No product-specific playlist is stored for this item yet. View IMC machine demonstrations and production videos in the main gallery.

View Machine Videos

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

Industrial Machinery Corporation is a widely known name in the world of industrial machine manufacturing and has been engaged in designing to exporting of various industrial machines since 2001. We have a huge list of clients for every type of machine that we produce and these clients range mainly from countries like USA, Mexico, Brazil, Venezuela, Ecuador, Korea, Turkey, India, UAE, Malaysia, Indonesia, Iran, Uzbekistan, Kazakhstan, Vietnam, Cambodia, Thailand, Syria, Jordan, Pakistan, Kuwait, Iraq, Nigeria, Egypt, Sudan, Ethiopia, Kenya, Tunis, South Africa, Ukraine, Russia, Belarus, Italy, Belgium, Macedonia and Greece. In our vast range of products, one machine that has gained huge popularity is the pipe end facing machine for which we are acknowledged as the best manufacturers. Our pipe end facing machine has all the qualities like durability, effectiveness, handiness, competency, efficiency, toughness and portability and these all qualities has made our pipe end facing machine, the most sold pipe end facing machine in the business. ? Our pipe end facing machine is used to chamfer or debarring of the pipes before they are sent for processes of galvanizing and threading. There are three tools fitted in our pipe end facing machine which makes it chamfer the pipes from in, out and front. The pipe in our Pipe End Facing Machine remains motionless and the facing head rotates. In the manual procession of a Pipe End Facing Machine, the slide moves towards the facing head for the chamfering process.

Following are some most prominent silent features of Pipe End Facing Machines manufactured by industrial machinery corporations:

• Handy portable and powerful tool

• Saves Customer’s time and money

• Self align design that enables the tool to mount into the pipe ID with a better grip

• Quick interchangeable designs of the pilot to suit a wide range of pipe ID

• Modular & Ergonomic design allows the tool to be used in confined space

• Offers high efficiency

• Durable

• Effortless operation, can be easily operated by a single person

• Available in different models and weight Following are some of the notable features if pipe end facing machine made by industrial machine corporation which distinguishes our machine from all pipe end facing machine present in the market of industrial machines today:

• Pipe End Facing Machine consists of a gear-driven cutter wheel with three major tool holders attached like a tool following wheel, a tool assembly, and a tool actuating spring

• Our Pipe End Facing Machine has the technique to cut accurate and precise bevels on heavy as well as thin-walled pipe ends to prepare any joint for welding

• Our Pipe End Facing Machine is operated using hydraulic power and uses a positive gear driven down with the motive of cutting accurate and précised bevels

• Our machine is available in different variants of pipe sizes such as 16” [404 millimeters] to 60” [1524 millimeters] • Apart from running by hydraulic power, this machine also comes in diesel and electric running modes Mentioned below are the names of various parts and tools that are combined together to makes one finest quality pipe end facing machine:

• Base

• Headstock

• Saddle

• Clamping vice

Specifications:

Model No.	IMC-EM- 1/2" to 1.1/2"	IMC-BM-1/2" to 4"
Min. Dia of Pipe to be Chamfered	1/2" N.B. Pipe	1/2"
Max. Dia of Pipe to be Chamfered	1.1/2"	4"
Cutting Tools Required (HSS 10% Cobalt)	3/8"	3/8"
Number of Spindle Speeds	Two nos.	Four nos.
Range of Spindle Speeds	37 to 64 RPM	68 to 180 RPM
Main Motor	3 H.P. 1440 RPM	3 H.P. 1440 RPM
Approx. Wt. of the Machine	750 Kgs.	1100 Kgs

Frequently Asked Questions About Pipe End Facing Machine

For this pipe end facing machine, what application check should come before purchase?

Review pipe dimensions and end-face requirements against the finished-component drawing before comparing models. Yes. State whether a square face, bevel or another profile is required. Confirm which end-preparation operations the proposed configuration includes.

Which details help IMC recommend the pipe end facing machine configuration?

Include pipe dimensions and end-face requirements, your material specification and required output. Describe how the workpiece arrives at this operation and where it goes next, so tooling, handling and any accessories can be discussed as part of the proposed setup.

How can I request this pipe end facing machine with the options I need?

Use the options listed on this product page and add the required quantity to your Quote List. In the final enquiry, identify pipe dimensions and end-face requirements, destination and electrical supply. Any tooling, installation or spare-part requirement should be stated explicitly for inclusion in the offer.
