Bandsaw Machine by Industrial Machinery Corporation

Bandsaw Machine by Industrial Machinery Corporation thumbnail

Bandsaw Machine by Industrial Machinery Corporation additional view 1

Bandsaw Machine by Industrial Machinery Corporation additional view 2

Bandsaw Machine by Industrial Machinery Corporation additional view 3

Bandsaw Machine by Industrial Machinery Corporation additional view 4

Review Metal Cutting Band Saw Machine for your component and the required production operation.

Define the component to be produced

This equipment is selected to cut suitable metal bars, rods, pipes and other sections with an appropriate bandsaw blade. A manufacturing enquiry needs the actual finished-part drawing and the condition of the starting material. List material grade, section shape and dimensions, cut length and quantity. Where several components are planned, separate their quantities and dimensions so that a model suitable for one item is not assumed to cover the entire range.

Match the process and tooling

Ask IMC to review blade selection, vice support, long-stock handling and the selected machine's cutting envelope for the component schedule. Clarify which tools are included for the first job and which are needed for a changeover. Solid and hollow sections can require different cutting conditions; provide the actual section rather than only its outside size. Preparation, material handling and any subsequent operation should appear in the production plan alongside this process.

Establish acceptance before ordering

A representative component should be checked for cut length, squareness and the end condition required for the next process. State the drawing requirements and how the result will be assessed. Use the published specifications to shortlist the model, then send the material and batch information with your chosen quotation options. Agree the supplied tooling, power requirements and support scope in the written offer.

Information to send with your enquiry

Material grade
Section shape and dimensions
Cut length and quantity

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Available options

Select the required options and add this machine to your quotation.

Available Options

Maximum Length Required

Min And Max Diameter of the Job

Model No You Are Interested

Expected Price

Purchase

Your selected configuration is stored in the existing Quote List flow for review before enquiry.

VIDEO REFERENCE

Machine Videos Gallery

No product-specific playlist is stored for this item yet. View IMC machine demonstrations and production videos in the main gallery.

View Machine Videos

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

With its formation in 2001, Industrial Machinery Corporation slowly but steadily started gripping the market of industrial machine manufacturing by designing and developing industrial machines like never before. We slowly became a dominant and famous supplier of industrial machines not by flashy advertisements but in all these ten years of being in business, our main concentration has stayed mainly on maintaining quality and not by blindly making machines with erratic and strange-looking designs. With all the experience gained in this world, we have developed a vast range of machines and one such machine that we have expertise in is the Bandaw Machine.

Key Features:

Rugged Construction: Crafted for durability, our Manual Bandsaw machines boast a sturdy construction that ensures stability during demanding cutting operations.
Precision Cutting Blade: Choose from a selection of precision blades designed for various materials. Maintain optimal tension for consistent and accurate cuts.
Secure Material Holding: The reliable vise securely holds materials in place, preventing any unwanted movement and guaranteeing precise cuts every time.
Intuitive Control Panel: Operate the machine with ease using the intuitive control panel. Start, stop, and make adjustments effortlessly for a seamless cutting experience.
Safety Features: Your safety is our priority. Our machines are equipped with advanced safety features, including blade guards and emergency stop mechanisms, creating a secure working environment.
Low Maintenance Design: Engineered for reliability, our manual bandsaw machines are designed for low maintenance, reducing downtime and ensuring continuous productivity.
Operating Steps:

Basic Components:

Frame: The robust frame forms the foundation, providing stability during cutting operations.
Blade: Choose the appropriate blade for your material and maintain optimal tension for efficient cutting.
Vise: The secure vise holds materials in place, preventing movement during cutting and ensuring precision.
Control Panel: Utilize the intuitive control panel for starting, stopping, and adjusting machine settings. Familiarize operators with these controls for efficient use.

Operating Steps:

Material Placement: Securely position the material in the vise, ensuring proper alignment for the desired cut.
Blade Selection and Tensioning: Choose the correct blade for your material and adjust tension according to manufacturer guidelines.
Power On: Activate the machine through the control panel, ensuring all safety measures are in place.
Feed Rate Adjustment: Tailor the feed rate to match the material, optimizing cutting performance.
Monitoring the Operation: Keep a close eye on the cutting process, making adjustments as necessary to ensure precision.
Power Off and Cleanup: After cutting, power off the machine, safely remove the cut material, and clean the machine for the next operation.

Empower your workshop with Industrial Machinery Corporation's Manual Bandsaw machines, where precision meets simplicity. Elevate your cutting operations with machinery you can rely on.

Specifications:

Model (unit)	HM-175	HM-200	HM-250	HM-300	HM-350	HM-400	HM-450
Capacity(mm)	175mm	200mm	250mm	300mm	350mm	400mm	450mm
Round(mm)	175mm	200mm	250mm	300mm	350mm	400mm	450mm
Square(mm)	150x150	150x150	200x200	250x250	300x300	350x350	400x400
Drive Motor (HP/ RPM)	0.5/1440	1/1440	1.5/1440	2/1440	2/1440	2/1440	3/1440
Coolant Pump (HP/ Volts)	0.15/440	0.15/440	0.15/440	0.15/440	0.15/440	0.15/440	0.15/440
Blade Speed (Meter / Minute)	25/30/40	20/35/55/75	20/35/55/75	35/55/75	35/55/75	35/55/75	35/55/75
Bandsaw Blade (mm)	2515x19x0.9	3000x27x0.9	3000x27x0.9	3760x27x0.9	4100x27x0.9	4420x34x1.1	4700x34x1.1
Floor Space LxWxH (mm)	1500x570x870	1630x580x895	2000x600x900	2400x830x1050	2550x830x1050	2650x830x1200	2800x830x1250
Net Weight (kg) approx.	250 kg	322 kg	400 kg	651 kg	600 kg	650 kg	700 kg
Packed Weight (wooden) approx.	330 kg	400 kg	500 kg	731 kg	800 kg	850 kg	910 kg

Frequently Asked Questions About Bandsaw Machine

For this bandsaw machine, what application check should come before purchase?

Review stock section and cutting angle against the finished-component drawing before comparing models. Solid, tubular and profiled sections place different demands on the blade and holding. Include maximum dimensions, material and intended cuts.

Which details help IMC recommend the bandsaw machine configuration?

Include stock section and cutting angle, your material specification and required output. Describe how the workpiece arrives at this operation and where it goes next, so tooling, handling and any accessories can be discussed as part of the proposed setup.

How can I request this bandsaw machine with the options I need?

Use the options listed on this product page and add the required quantity to your Quote List. In the final enquiry, identify stock section and cutting angle, destination and electrical supply. Any tooling, installation or spare-part requirement should be stated explicitly for inclusion in the offer.
