Portable Pipe & Bolt Thread Cutting Machine Manufacturer

Portable Pipe And Bolt Threading Machine by Industrial Machinery Corporation

Portable Pipe And Bolt Threading Machine by Industrial Machinery Corporation thumbnail

Review Portable Pipe & Bolt Thread Cutting Machine for your component and the required production operation.

Define the component to be produced

This equipment is selected to prepare external threads on compatible pipe and bolt workpieces with appropriate threading tools. A manufacturing enquiry needs the actual finished-part drawing and the condition of the starting material. List pipe and bolt sizes, materials, thread forms, lengths and site utilities. Where several components are planned, separate their quantities and dimensions so that a model suitable for one item is not assumed to cover the entire range.

Match the process and tooling

Ask IMC to review the separate tooling required for pipe and bolt jobs, holding arrangements and size changeovers for the component schedule. Clarify which tools are included for the first job and which are needed for a changeover. List pipe and bolt work separately so that the quotation identifies the dies and accessories for each application. Preparation, material handling and any subsequent operation should appear in the production plan alongside this process.

Establish acceptance before ordering

A representative component should be checked for the pipe connection thread and bolt thread against their respective drawings. State the drawing requirements and how the result will be assessed. Use the published specifications to shortlist the model, then send the material and batch information with your chosen quotation options. Agree the supplied tooling, power requirements and support scope in the written offer.

Information to send with your enquiry

Pipe and bolt sizes
Materials
Thread forms
Lengths and site utilities

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Available options

Select the required options and add this machine to your quotation.

Available Options

Thread Type

Purchase

Min And Max Diameter of the Job

Expected Price

Your selected configuration is stored in the existing Quote List flow for review before enquiry.

VIDEO REFERENCE

Machine Videos Gallery

No product-specific playlist is stored for this item yet. View IMC machine demonstrations and production videos in the main gallery.

View Machine Videos

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

A portable pipe and bolt threading machine is more often than not, fitted with a system that is truly advanced. This allows for the machine to function not just smoothly, but also in a manner that is hassle free. High level quality processes and constant checks also ensure that the amount of money and time spent on maintenance is minimal. Apart from this, there is also the guarantee that the ultimate output offered will be on the higher side.

Some of the signs of a good and reliable portable pipe and bolt threading machine would be that it incorporates features such as a resistance to abrasion and water. The machines have been built to withstand wear and tear as well as breakage. This ensures that whoever invests in this machine, receives full value for the money spent.

Companies like Industrial Machinery Corporation offer portable pipe and bolt threading machine that are fabricated in accordance with the specifications provided by the customer. These include sizes for pipes, bolts, conduits, etc.

Portable Pipe and Bolt Threading Machine

Model No.	IMC-PPBTM-1/2" to 2"
Sizes for Pipe (Inches)	1/2" to 2"
Sizes for Bolts	3/8" - 2 & 10 MM - 33MM
Sizes for Conduits	1/2" - 2 & 12MM - 30 MM
Specifications	230V/50 Hz., 750W, 27 RPM
Die-Head(Inch.)	1/2" - 2
Dies Including (Inch.) BSPT or NPT	1/2" - 3/4" & 1 - 2"
Approx. Wt. of the Machine	62 Kgs.

Frequently Asked Questions About Portable Pipe And Bolt Threading Machine

For this portable pipe and bolt threading machine, what application check should come before purchase?

Review site supply and the pipe and bolt ranges against the finished-component drawing before comparing models. Do not assume it can. Identify both thread standards and ask which die heads, dies and accessories cover the planned jobs.

Which details help IMC recommend the portable pipe and bolt threading machine configuration?

Include site supply and the pipe and bolt ranges, your material specification and required output. Describe how the workpiece arrives at this operation and where it goes next, so tooling, handling and any accessories can be discussed as part of the proposed setup.

How can I request this portable pipe and bolt threading machine with the options I need?

Use the options listed on this product page and add the required quantity to your Quote List. In the final enquiry, identify site supply and the pipe and bolt ranges, destination and electrical supply. Any tooling, installation or spare-part requirement should be stated explicitly for inclusion in the offer.

RELATED PRODUCTS

Portable Pipe Threading Machine
