Bar Threading Machine

• Since our formation, we have specialized in manufacturing the finest quality Bar Threading Machines. The Bar Thread Cutting Machine that we manufacture has all the qualities that have made our machines, the most used, recommended as well as searched Bar Thread Cutting Machine. Only the finest quality raw material is used to build not only our Bar Thread Cutting Machines but also our machines and this ensures us all our machines will be sturdy, vigorous, and strong enough to face the wear and tear arising in factories and tool rooms. The Bar Thread Cutting Machines made by us are specially designed and manufactured to provide a maximum of working hours to the buyers and impose a minimum maintenance cost. Our Bar Threader runs on a chasing machine and in fact, most of our machine runs on the same principle as there are absolutely no chances of any fault or defect in the chasing method. While working on the chasing method, the Bar Thread Cutting Machines makes the pipe stay stable in one place and allows the die head to rotate around it precisely producing accurately drawn threads. Following are the features of the Bar Thread Cutting Machine manufactured by us at our Ludhiana unit:

Bar Thread Cutting Machines with Mechanical Unit with Hand Operated

Motor Capacity 5 HP with Couple Pump Machine threading Capacity 16 mm to 40 mm (160 mm length of threading)

Heavy Cutting Blade

Machine Weight 300 Kg (Change for Models)

These are capable of threading several tons of TMT/TOR steel every day without any trouble

10 Liters Cutting oil capacity

Below is the list containing the names of cuts, a Bar Thread Cutting Machines manufactured at an industrial machinery corporation can cut:

• BSP
• BSPT
• NPT
• UNF
• UNC
• BSW
• Acme

Following are the names of various parts and components that assemble together to make the finest quality Bar Threader :

Base
• Head Stock
• Saddle
• Pillar Or Bed Type Clamping Vice
• Die Head

Let’s have brief info on each of these components one by one:

Head Stock: - A heavy-duty geared Head Box is of the best quality casting providing support to the spindle bearings. The box is of gear type, lubricated, and fitted with three extra heavy-duty bearings.

• The Bed: - The bed is pillar type having two pillars made of best quality steel nicely finished & duly hard chrome plated in the most modern hard chrome plating unit.
•

• The Saddle: - The Saddle is fitted on two pillars very precisely. It runs on pillars very smoothly and accurately to the Head Stock alignment.
•

• The Apron: - The apron gives movement to the saddle with head transfer along with pillars through steel rack and pinion arrangements. It's all gears are made of the best quality steel.
•

• Vice Jaws: - The vice jaws made from the best quality alloy steel are fitted on the saddle well aligned with the head stock center fitted in a heavy duty box type vice. The jaws are heat treated. The movements of the jaws are controlled by a screw on the saddle.

Range of Bar Threader that we build here at the manufacturing unit of the industrial machinery corporation located in Ludhiana:

• 3/8'' to 1.12'' do/-
• 1/2'' to 2 .1/2" do/-
• 1" to 4" do/-

Bar Thread Cutting Machine Specifications

IMC Tangential Chasers are manufactured from imported High-Speed Steel which must pass exacting metallurgical standards. Experienced heat treatment with the automatically imported heat treatment plant and imported Testing equipment, assures that they will perform satisfactorily in service and produce quality threads within the tolerance for which they were intended.

IMC Chaser is interchangeable. If one Pc. Of a chaser, set is damaged & is beyond use. The same No. pc. The other chaser set lying in stock may be used and there will not be any difference in thread cutting performance and the damaged set can be replaced without the necessity of replacing the entire set.
